BMW MSV80 MSV80.0 MSV80.1 - 2FA4 Incorrect Data Record Repair

BMW MSV70 MSV80 MSD80 MSD81 - 2F49 A102 Anti Tampering Protection

Name: BMW MSV70 MSV80 MSD80 MSD81 - 2F49 A102 Anti Tampering Protection
Brand: Rpm Motorsport
SKU: anti-tampering
Price: 719.2 USD
Availability: InStock

Save $179.80 USD

$899.00 USD

$719.20 USD

Quantity

1 to 2 Business days turnaround time upon arrival
Overnight shipping both ways using our UPS shipping label

Product Information

This is a BMW Repair Service for any E-Series with N51 and N52N engines equipped with DME MSV80, MSV80.0 , MSV80.1, MSD80 and MSD81 that have the following BMW Fault codes (See Popular Fault Codes):

Popular Fault Codes

2F49 -- Anti tampering protection
2F4C -- EWS DME message incorrect
A102 -- Immobilizer anti tampering protection

The reason this happens is because the CAS Module and DME (Engine control unit) loses its Sync Code between them. Even with an Autologic or ISTA-P you will NOT be able to make a CAS-DME Alignment. The Only way this will work is that you send us your DME, CAS and Key.

Models Supported

BMW 3 Series E90 325i 01/2005 to 08/2006
BMW 3 Series E90 323i 03/2005 to 08/2006
BMW 3 Series E90 325xi 09/2004 to 08/2006
BMW 3 Series E90 330i 02/2004 to 08/2006
BMW 3 Series E90 330xi 03/2005 to 08/2006
BMW 5 Series E60 525i 07/2004 to 02/2007
BMW 1 Series E82 128i From 12/2006 To 10/2013
BMW 3 Series E90 323i From 01/2007 To 12/2011
BMW 3 Series E90 - E92 328i From 01/2007 to 06/2013
BMW 3 Series E90 - E92 328xi From 01/2007 To 06/2013
BMW 5 Series E60 LCI 528i Years 05/2006 To 12/2009
BMW 5 Series E60 LCI 528xi Years 05/2006 To 12/2009
BMW X5 Series E70 3.0si / 3.0L From 08/2006 To 03/2010
BMW Z4 Series E89 23i / 28i / 30i From 07/2008 To 08/2011
BMW 1 Series E82 135i From 12/2006 To 10/2013
BMW 1 Series E88 135i From 12/2006 To 10/2013
BMW 3 Series E90 335i From 08/2006 To 12/2009
BMW 3 Series E91 335xi From 08/2006 To 12/2009
BMW 3 Series E92 335i From 08/2006 To 12/2009
BMW 3 Series E93 335i From 08/2006 To 12/2009
BMW 5 Series E60 535i / 535xi From 04/2008 To 12/2009
BMW Z4 Series E89 35i From 07/2008 To 08/2016
BMW Z4 Series E89 35is From 07/2008 To 08/2016
BMW X6 Series E71 X6 35iX SAC From 01/2007 To 12/2009

DME / ECU SUPPORT LIST

MSV70 DME'S (ECU) AKA N52 Engines.

DME Supported Part Number (Siemens MSV70)

7552398 - 7552399 - 7553166 - 7553167
7555361 - 7555362 - 7559178 - 7559179
7561817 - 7561818 - 7561684 - 7561685
7567179 - 7567180 - 7577969 - 7577970

MSV80 / MSV80.0 / MSV80.1 DME'S (ECU) AKA N51 and N52N Engines.

DME Supported Part Number (Siemens MSV80)

7546143 - 7557135 - 7565861 - 7565862
7567227 - 7567230 - 7567362 - 7567367
7569988 - 7570376 - 7570398 - 7573322
7573323 - 7574540 - 7574541 - 7574544
7574545 - 7575057 - 7575058 - 7575498
7575499 - 7576297 - 7576300 - 7577068
7577069 - 7577996 - 7577997 - 7581123
7581124 - 7583468 - 7583470 - 7587164
7587165 - 7591709 - 7591710 - 7594483
7594484 - 7594941 - 7594942 - 7597091
7597093

DME Supported Part Number (Siemens MSV80.0)

7602220 - 7602221 - 7605429 - 7605430
7609656 - 7609657 - 7611280 - 7611281
7614359 - 7614361 - 7624048 - 7624049

DME Supported Part Number (Siemens MSV80.1)

7567609 - 7567610 - 7569989 - 7573332
7574542 - 7574543 - 7574546 - 7574547
7575500 - 7575501 - 7576670 - 7576671
7581126 - 7581127 - 7581547 - 7581548
7583526 - 7583527 - 7584309 - 7584310
7587166 - 7587167 - 7591843 - 7591844
7594485 - 7594486 - 7597425 - 7597426
7602216 - 7602217 - 7605423 - 7605424
7609658 - 7609659 - 7611282 - 7611283
7614362 - 7614363 - 7624052 - 7624053
7629046 - 7639647 - 8613002

MSD80 / MSD81 / DME (ECU) with N54 / N54T Engines.

DME Supported Part Number (Siemens MSD80)

7546141 - 7550014 - 7565859 - 7565860
7567229 - 7567232 - 7567491 - 7567492
7567542 - 7567543 - 7568370 - 7568371
7568842 - 7568843 - 7569978 - 7569979
7571468 - 7571469 - 7572063 - 7572064
7572067 - 7572068 - 7573796 - 7573797
7573863 - 7573864 - 7574534 - 7574535
7575875 - 7575876 - 7576719 - 7576720
7576721 - 7576722 - 7578020 - 7578021
7578441 - 7578442 - 7583332 - 7583333
7586938 - 7586939 - 7586940 - 7586954
7588620 - 7588621 - 7594305 - 7594306
7595235 - 7595236 - 7596017 - 7596018
7611396 - 7611397

DME Supported Part Number (Siemens MSD81)

7578033 - 7578034 - 7579011 - 7579012
7583324 - 7583325 - 7585540 - 7585541
7585711 - 7585712 - 7585889 - 7585890
7586933 - 7586934 - 7590871 - 7590872
7592080 - 7592081 - 7593493 - 7593494
7596019 - 7596020 - 7596022 - 7596021
7600427 - 7600428 - 7601865 - 7601866
7602118 - 7602119 - 7604567 - 7604568
7604593 - 7604594 - 7605662 - 7605663
7608621 - 7608622 - 7611358 - 7611359
7612455 - 7612456 - 7614620 - 7614620
7616431 - 7616432 - 7618935 - 7618936
7622911 - 7622912

DME & CAS Removal

I was very satisfied with the operation that you performed for my DME and cast it worked perfectly and I think you very much and I’m sure I will be using you in the future graham

Thanks for the review Graham!

Quick turnaround

They were honest with the diagnosis and return.
Would use them again at a drop of a hat.

Happy to hear that Steve! Looking forward to working with you again soon!

Reprogrammed the CAS and DME for my Z4

I own a 2009 BMW Z4. The battery had gone dead and that caused all sorts of problems. I replaced the battery but then the car would turn over but not start. I took the car to two local repairs shops that work on BMWs and they were not able to get it running. All they were able to determine was my car was in lock out due to the anti-theft being triggered. Their "solution" for the problem was to replace the CAS and probably the DME also. VERY expensive and the parts were back ordered. It would be at least 2 or 3 months before the parts were available, if then. I did some research and found a number of sites that claimed to be able to reprogram the CAS and DME to resolve the problem and RPM Motorsports stood out due to their references. I called them and ended up working with Lee. He was fantastic. I explained the problem and he diagnosed the problems and the fix which involved reprogramming the CAS and DME so they were properly sync'd. Lee explained they would send me an overnight shipping label that I would use to send the CAS, DME, and key fob to them. I received an email with the UPS label attachment and printed it out and took the package to UPS. 3 days later I received the reprogrammed CAS and DME and key fob. Installed them and the car started immediately and there were no other problems. Everything worked as it should. Lee in particular and RPM in general were great to work with and I would highly recommend contacting them if you have problems with your BMW. The service was great and they know what they are doing and the price was extremely reasonable.

Thanks so much for sharing your experience and for the kind words Jim!
